Introduction

Alumni Spaces maintains two public APIs:

contentAPI for accessing content created by groups
vaultAPI for accessing transaction data from Alumni.Fund.

At the moment, only vaultAPI is documented. If you need access to contentAPI, please let us know.

The production URL for API access is https://vault.alumnispaces.com

For testing purposes, you may also use https://vault-dev.alumnispaces.com

Authentication

To access any Alumni.Fund data, you'll first need to get two things from our team.

HTTP Basic authentication username and password
A valid API key - it is an alphanumeric string that determines your data access and "verb" permissions. We use this key to determine which institutions you have data right to and if you are allowed to GET, POST, PUT or DELETE. This API key is passed to our API using a custom header: x-alumnispaces-key

All requests require the presence of both authentication methods.

Any request that does not contain both authentication methods will be rejected.

Alumni.Fund Vault

Entities

Alumni.Fund's Vault contains two entities: Person and Transaction.
In the plural, they are referred to as People and Transactions.
As you might imagine, a Person is the instigator of a Transaction.
Each Person has a unique ID which is the only part of their identity that is stored with the Transaction record.

At the moment, we do not de-duplicate or combine Person records, so Tyrion Lannister might have 5 different Person records to match the 5 transactions he's conducted. This is anticipated to change in the future. Transactions on the other hand, will always represent a single instance where funds are processed.

Update Timestamps

Example of _updated timestamps for object properties

"emails": [
  {
    "label": "work",
    "_updated": "2017-08-10T21:58:04.773Z",
    "address": "tlannister@meereen.gov"
  },
  {
    "label": "personal",
    "_updated": "2016-07-10T21:58:16.403Z",
    "address": "tyrionthetall@wmail.com"
  }
]

When a record is created for either a Person or a Transaction, we add a _created property to the record which contains as ISO8601 timestamp. If that record is ever updated, we add an _updated property with that timestamp. Almost every record will have an _updated value because it usually takes a few seconds for our code to communicate with the payment processing system or our own internal APIs.

Example of _updated timestamps for non-object

"_contentID_updated": "2017-04-07T20:02:13.044Z",
"_asSiteID_updated": "2017-04-07T20:02:13.044Z",
"_status_updated": "2017-04-07T20:02:13.044Z",
"_taxed_updated": "2017-04-07T20:02:13.044Z",

Thinking ahead, it is reasonable to assume that we'll be updating Person records regularly as the Person perform more transactions, our data is integrated into more systems or we add additional data management features. So, we also maintain a per-property _updated value.

When a property is updated, you'll see a timestamp of when that update occurred. If the property is a nested object (like emails), we'll add the timestamp within that object. If the updated property it is not a nested object, we'll add the timestamp at the root of the record object using an underscore prefix and the property name. For example: _status_updated: or _disbursement_updated:

People

Example Person Record

{
  "_id": "598cd8a53fw352252b6ffqc",
  "_created": "2017-08-10T22:05:25.561Z",
  "_updated": "2017-08-10T22:05:35.253Z",
  "contentIDs": [
    "westeros_20_135",
    "westeros_35_123"
  ],
  "asSiteIDs": [
    "westeros_20",
    "westeros_35"
  ],
  "name": {
    "first": "Tyrion",
    "last": "Lannister",
    "_updated": "2015-09-01T17:28:23.781Z"
  },
  "addresses": [
    {
      "label": "Dorne Vacation Home",
      "company": "Lannister Family",
      "validStart": "05.08.1982",
      "validEnd": "11.11.2009",
      "addr1": "412 S. Sandsnake Dr.",
      "addr2": "Penthouse Suite",
      "city": "Sunspear",
      "region": "Dorne",
      "country": "Dorne",
      "postal": "1"
    }
  ],
  "emails": [
    {
      "label": "work",
      "_updated": "2017-08-10T21:58:04.773Z",
      "address": "tlannister@meereen.gov"
    },
    {
      "label": "personal",
      "_updated": "2016-07-10T21:58:16.403Z",
      "address": "tyrionthetall@wmail.com"
    }
  ],
  "organizations": [
    {
      "name": "The Iron Throne",
      "orgType": "Government Body",
      "startDate": "01.01.1995",
      "endDate": "01.01.1997",
      "title": "Hand of the King",
      "prevTitles": [ "Brother-in-law", "Nuncle" ]
    }
  ],
  "externalIDs" : [
    {
      "_updated": "2017-08-10T22:05:25.561Z",
      "key": "braintree",
      "value": null,
      "_id": "5953432579ger6b624g3d"
    },
    {
      "_updated": "2017-07-11T12:35:15.561Z",
      "key": "yourExternalDB",
      "value": "lannister_t",
      "_id": "09998122j"
    }
  ],
  "gender": "male",
  "birthday": "01.01.1971",
  "Twitter": {
    "username": "the_pImp"
  },
  "phones": [
    {
      "label": "pager",
      "number": "1234"
    },
    {
      "label": "mobile",
      "number": "5678"
    }
  ],
  "urls": [
    {
      "label": "Wikipedia",
      "value": "https://en.wikipedia.org/wiki/Tyrion_Lannister"
    }
  ]
}

A person is a core object in the Alumni.Fund Vault API. A person is exactly that: a warm-blooded human for home we have some amount of data. A person is created when one of the following things occurs:

They perform a transaction through our system, either a purchase or donation
(future) They RSVP or check in at an event managed by the Alumni Spaces platform
(future) A member of a local group or national alumni association manually enters some information about this person

A person

People have the following attributes (bold indicates top level object element)

Response Parameter	Definition	Type	Example
_id	Unique identifier for this person	string
_created	Date this Person's record was first created	string as ISO8601 Date
_updated	Date this Person's record was last updated	string as ISO8601 Date
name	Object containing Person's name	object
name.first	Person's first name	string
name.last	Person's last name	string
addresses	Array of objects containing address records	Array	object
address.label	Text label for this address record	string	"Home", "Office","Summer home"
address.company	Company name for business address	string	"ACME, Inc"
address.validStart	Beginning of date range for which this is/was a valid address	string as ISO8601 Date
address.validEnd	End of date range for which this is/was a valid address	string as ISO8601 Date
address.addr1	First line of address	string	68 Jay St
address.addr2	Second line of address	string	Suite 503
address.city	Town/City name	string	Brooklyn
address.region	Region/State name	string	New York
address.country	Country name	string as ISO 3166-1 Alpha-2 abbreviation	US
address.postal	postal/zipcode	string	11201
facebook	Object containing identifying info for facebook	object
facebook.identityToken	Token saved if user has authenticated with the Alumni Spaces Facebook App. Internal use only, not returnable.	string
facebook.displayName	Name user has chosen to display on Facebook	string
facebook.ID	Unique numerical id for Facebook profile	number
twitter	Object containing Twitter profile data	object
twitter.username	Twitter id without @ symbol	string	acafourek
linkedin	Object containing LinkedIn profile data	object
linkedin.username	Unique username on LinkedIn	string	andrew.cafourek
emails	Array of objects containing email data	Array
email.label	Text label for email field	string	Personal
email.address	Email address	string	andrew@gmail.com
phones	Array of objects containing phone numbers	Array
phone.label	Text label for phone field	string	Cell
phone.number	Phone number, stripped of non numeric characters	string (intentionally left as string instead of number)
externalIDs	Array of objects containing ID values for 3rd party services. Objects follow standard key/value format but could have custom attributes added.	Array
external.:serviceid:	Contains string with ID for external service. Service is known by the key, standardization of 3rd party services will be available later.	object	skype:"acafourek"
organizations	Array of objects representing employment, volunteer or involvement history	Array
organization.name	Text name of company/organization	string	Alumni Spaces
organization.orgType	Category of affiliation with this organization.	string	Governmental
organization.startDate	ISO 8601 date of beginning of affiliation	string
organization.endDate	ISO 8601 date of end of affiliation	string
organization.title	Applicable title to describe this person's role in the organization	string	Chief Technical Officer
organization.prevTitles	Titles that have previously been assigned to the organization.title value	Array	Jr. Javascript Developer, Sr. Technical Manager, Director of Engineering
organization.linkedinID	LinkedIn ID of this organization	string
urls	Array of objects in the familiar label/value format	Array
url.label	Textual label for this url field	string
url.value	Valid url	string
groups	Alumni Spaces groups this person is affiliated with	Object
groups.:groupid:	Key is Group ID in the Alumni Spaces system, Value is readable name	String	mizzou_34:"New York Mizzou Alumns"
gender	Person's identified gender	String
birthday	ISO 8601 Date of Person's birthday	String
contentIDs	Array of strings- if a Person creates a Transaction via Alumni.Fund, the contentID affiliated with that Alumni.Fund flow is saved here.	Array
asSiteIDs	Array of strings- if a Person creates a Transaction via Alumni.Fund, the recipient group's unique ID is added to this Array	Array

Get a Person

You can fetch the record of an individual by using a GET request accompanied by the Person's id number.

HTTP Request for Person

GET https://vault.alumnispaces.com/person/{id}

URL Parameters for Person

Parameter	Description
ID	The ID of the Person to retrieve

Get All People

You can fetch a full list of all people by using a GET request to the /person endpoint.

HTTP Request for Person

GET https://vault.alumnispaces.com/person/

Create a Person

Response when creating a Person

    {
      "_id": "5653b26dd75eafac08185b3e"
    }

Creating a person simply requires making a POST to the /person endpoint with JSON-formatted profile data. When successfully created, an ID is returned.

Transactions

Example Transaction Record

{
        "_id": "583dd1d6daaab713f8a7a4d8",
        "_created": "2016-11-29T19:07:02.905Z",
        "_updated": "2016-11-29T19:07:16.221Z",
        "_method_updated": "2016-11-29T19:07:02.905Z",
        "_contentID_updated": "2016-11-29T19:07:02.905Z",
        "_asSiteID_updated": "2016-11-29T19:07:02.905Z",
        "_status_updated": "2016-11-29T19:07:02.905Z",
        "_taxed_updated": "2016-11-29T19:07:02.905Z",
        "_currency_updated": "2016-11-29T19:07:02.905Z",
        "_value_updated": "2016-11-29T19:07:02.905Z",
        "value": 25,
        "currency": "USD",
        "transDate": "2016-11-29T19:07:02.000Z",
        "person": "583dd1d6dagbe323522",
        "taxed": true,
        "status": "settled",
        "asSiteID": "oklahoma_23",
        "contentID": "oklahoma_23_223",

        "method": "credit_card",
        "disbursement" : {
            "complete" : true
        },
        "__v": 0,
        "note": [
            "Notes go in this space!"
        ],
        "items": [
            {
                "_updated": "2016-11-29T19:07:02.905Z",
                "label": "Lifetime Membership",
                "price": 25,
                "_id": "583dd1d6daaab713f8a7a4da"
            }
        ],
        "receipt": {
            "to": "tlannister@meereen.govv",
            "emailID": "log_66c55cd19as38276a60afde4119b2fd34c-3",
            "emailService": "Sendwithus",
            "sent": true,
            "_updated": "2016-11-29T19:07:16.221Z"
        },
        "external": [
            {
                "_updated": "2016-11-29T19:07:02.905Z",
                "key": "braintree",
                "value": "hdrqf3zg",
                "_id": "583dd1daggwqq13f8a2512d9"
            }
        ],
        "extra_fields": [
            {
                "value": "2007",
                "label": "Year of graduation",
                "field_type": "text",
                "id": "year_of_graduation",
                "_updated": "2017-08-10T16:08:39.574Z",
                "_id": "598c85071d18fa6948f21afa"
            },
            {
                "value": "english",
                "label": "Major",
                "field_type": "text",
                "id": "major",
                "_updated": "2017-08-10T16:08:39.574Z",
                "_id": "598c85071d18fa6948f21af9"
            },
            {
                "value": "1234556",
                "label": "Member ID",
                "field_type": "text",
                "id": "member_id",
                "_updated": "2017-08-10T16:08:39.574Z",
                "_id": "598c85071d18fa6948f21af8"
            }
        ]
    }

A transaction is a base object in the Alumni.Fund Vault API which describes a financial exchange within a 3rd party system.

Buying stuff

What a transaction is not

Note that this object and its associated methods are for logging and recording, there are no methods to support the actual completion of a financial transaction. POST actions add Transaction records, they do not initiate actual Transactions.

Transactions have the following attributes (bold indicates top level object element)

Response Parameter	Definition	Type	Example
_id	Unique identifier for this transaction	string	"1234ABCD"
_created	Date this Transaction's record was first created	string as ISO8601 Date
_updated	Date this Transaction's record was last updated	string as ISO8601 Date
type	Classification of what kind of transaction this is	string	Donation, Purchase, Ticket
value	Currency value of the transaction. Only valid characters are numbers and decimal	number	10.00
currency	ISO 4217 currency code	string	USD,GBP
method	Payment method used	string	credit_card, Venmo, Check
physical	Was transaction completed in-person?	boolean	true/false
transDate	ISO 8601 date of transaction timestamp	string	2015-07-05T22:16:18+00:00
person	Unique ID of person created by or mapped to this transaction (see /people/:id method)	string	1234
taxed	Was tax charged on this transaction?	boolean	true/false
external	Object containing external data objects affiliated with this transaction, allowing us to map data between transaction systems	object
disbursement	Object containing data about payout of the funds associated with this transaction	object
disbursement.complete	Indicator for whether funds from this transaction have been paid out to client by Alumni Spaces.	boolean	true/false
receipt	Object containing information about customer notification	object
receipt.sent	Boolean indicator for receipt sent status	boolean	true/false
receipt.emailID	External mail service ID of receipt email. Mandrill ID, etc	string
receipt.to	Email address where receipt is to be sent	string	tester@gmail.com
receipt.service	Provider used to deliver receipt	string	Sendwithus
source	Object containing some basic info about how this transaction was obtained	object
source.channel	Medium through which customer was obtained	string	Facebook, email, event
source.interface	Tool the customer interfaced with to process payment	string	web, checkin, email
source.campaign	Campaign code used in channel	string	October_Watch_Party_email3
source.id	ID code used in campaign	string	12345
contentID	Alumni Spaces Content ID affiliated with this transaction	string	testnetwork_93_18
asSiteID	Alumni Spaces Group ID affiliated with this transaction	string	testnetwork_93
status	Some payment methods are not completed right away and a transaction is not considered funded and complete until status = settled	string	pending/failed/settled/refunded
note	Array field of text notes that may be affiliated with transaction	Array
items	Array of objects describing what "product" was purchased in this flow. Alumni.Fund will show $5,$10,$20, etc by default but this may be customized by group or network.	Array
item.label	Group or network-provided text label for the product purchased. If not present, there were no custom products defined and the Person selected an Alumni.Fund default of $5, $10, $20, etc. (as described in the `value` property)	String	Membership
item.price	If custom product was purchased, it's sale price is saved here. Should be the same as the `value` property	Number	85
extra_fields	Array of objects describing additional fields added to the Alumni.Fund flow by the group or network. This is currently limited to 3 fields.	Array
extra_field.id	Programmatically-created "unique" identifier for this field. Simple strip/replace of the `item.label` to remove non-alphanumerics and replace spaces with underscores. Note: this will not have an underscore prefix. There is likely to be an auto-generated `_id` in this object as well	String	year_of_graduation
extra_field.label	Group or network-provided label for this field	String	Year of Graduation
extra_field.field_type	Field type. Currently, extra fields may be `checkbox`, `dropdown` or `text`	String	"text"
extra_field.value	Person-supplied value for this field.	String	"Summer 2007"

Get a Transaction

You can fetch the record of a transaction by using a GET request accompanied by the transaction ID number.

Fetch transaction ID 58d7d9187200bc2fbbff77f1

GET https://vault.alumnispaces.com/transaction/58d7d9187200bc2fbbff77f1

HTTP Request for Transaction

GET https://vault.alumnispaces.com/transaction/{id}

URL Parameters for Transaction

Parameter	Description
ID	The ID of the Transaction to retrieve

Create a Transaction

Response when creating a Transaction

    {
      "_id": "58d7d9187200bc2fbbff77f1"
    }

Creating a transaction simply requires making a POST to the /transaction endpoint with JSON-ready data passed as parameters. When successfully created, a Transaction ID is returned.

Update a Transaction

Updating a transaction simply requires making a PUT request to the /transaction endpoint with JSON-ready data passed as parameters. When successfully updated, the full, updated Transaction record is returned.

Querying Transactions

Example request combining Order and Grouping parameters (records truncated for readability)

GET https://vault.alumnispaces.com/transaction/query?order=DESC&order_by=value&group_by=asSiteID

{
  "bigstate_19": [
      {
        "_id": "596453247e9213434132811",
        "_created": "2017-07-11T02:26:15.715Z",
        "value": 900
      },
      {
        "_id": "593252247e92233434132231",
        "_created": "2017-07-11T14:55:09.769Z",
        "value": 800
      },
      {
        "_id": "131252247e9223343098021",
        "_created": "2016-06-12T14:12:08.121Z",
        "value": 500
      },
  ],
  "bigstate_37": [
      {
        "_id": "324237e92134341332523",
        "_created": "2013-09-04T02:26:15.715Z",
        "value": 100
      },
      {
        "_id": "080252247e9223343877",
        "_created": "2015-11-25T14:55:09.769Z",
        "value": 75
      },
      {
        "_id": "566247e92233430780082",
        "_created": "2016-06-12T14:12:08.121Z",
        "value": 50
      },
  ],
}

The Vault supports a number of query parameters that can make it easier to fetch and handle data in meaningful ways. All queries are a part of the /transaction/query/ endpoint and depend on additional query parameters.

Return Grouping and Ordering

You may request that the Transaction records be returned in specific groups, orders or ask us to do some math before sending it back to you.

Parameter	Description	Example
`order`	Change the order of the returned data. Must be used with `order_by`	`ASC` (default), `DESC`
`order_by`	The field that `order` should be based upon. Will work with any first-level field based on alphabetic or numerical order. (Date fields will inherently work in alpha/numeric ordering since they are in ISO format)	`value`, `transDate`, `_updated`
`group_by`	Group records based on a shared property value. The `group_by` value will become the parent to the transaction records contain within it (see example JSON) Supports `person`, `status`, `taxed`, `contentID`,or `asSiteID`	`asSiteID` will return records within parent objects such as `littlestate_39` and `oklahoma_123`

Return Aggregate Math

Example of aggregation math

This request says to aggregate by asSiteID and return the sum of the "value" fields within those asSiteIDs
GET https://vault.alumnispaces.com/transaction/query?aggregate_by=asSiteID&aggregate_sum=value

[
    {
        "_id": "bigstate_39",
        "_count": 6,
        "value_sum": 185
    },
    {
        "_id": "bigstate_38",
        "_count": 1,
        "value_sum": 20
    },
    {
        "_id": "bigstate_21",
        "_count": 6,
        "value_sum": 120
    },
    {
        "_id": "bigstate_18",
        "_count": 1,
        "value_sum": 10
    }
]

You may also want to quickly determine "What is the total value of all transactions per group?" or "What is the most recent transaction date?". To help with this, Vault provides aggregate math parameters.

Aggregation parameters work with order and order_by query parameters but will not work when combined with Return Filtering parameters.

Parameter	Description	Example
`aggregate_by`	Requesting aggregate data will not return any `Transaction` records. Instead, you'll get grouped math summaries of the data within those records. This parameter is very similar to `group_by` and accepts the same options as `group_by`. Requires `aggregate_{method}` parameter.	(See code example)
`aggregate_{method}`	This parameter uses both the key and value to determine your request. {method} may be `sum`, `avg`, `min` or `max` while the parameter's value should be a `Transaction` property.	`aggregate_sum=value`, `aggregate_min=transDate`

Aggregation Request Examples


When was the most recent transaction for each group?	`/transaction/query?aggregate_by=asSiteID&aggregate_max=transDate`
What is the average payment value for a particular event?	`/transaction/query?aggregate_by=contentID&aggregate_avg=value`
What is the average payment value for a particular event?	`/transaction/query?aggregate_by=contentID&aggregate_avg=value`
What is the total value of all transactions still pending settlement?	`/transaction/query?aggregate_by=status&aggregate_sum=value`

Return Filtering

You may also request records based on field value or transaction data (transDate). Returned data will be in the same format as expected from a vanilla /transaction or group_by request.

These filter options may be combined with order, order_by and group_by parameters to customize return format.

Date Ranges

Parameter	Description	Example
`transDate_start`	Only return transactions that occurred after this date. Format YYY-MM-DD.	`transDate_start=2017-06-01`
`transDate_end`	Only return transactions that occurred before this date. Format YYY-MM-DD.	`transDate_end=2017-08-10`

You may use transDate_start and transDate_end to create a range. Ranges are only inclusive of the start date: requesting June 1 - August 10 means you're asking for data from 12:01AM on June 1 through 11:59PM on August 9.

Field Filter

You may also add a parameter to limit by any field value by simply using {field}: {value}

Examples:


Get all transactions for specific group	`/transaction/query?contentID=bigstate_38_268`
Get all transactions where `disbursement.complete` is true. Also demonstrates targeting nested fields in queries	`/transaction/query?disbursement.complete=true`
Get all transactions for specific `Person` ID	`/transaction/query?person=58e7f3252192134341749143347c3`
